SYNTHETIC ROLL MEDIA

Synthetic fibre filter media, class from G2 to F5 according to EN 779:2012. Available in rolls, panels and roll filters.

APPLICATIONS

Filtration of airborne particles in civil and industrial air conditioning systems. It is commonly also
used as pre-filtration stage before the fine dust filters. Ideal for air handling units, office,
laboratories, air conditioning, compressor and blowers, motor control rooms, paint spray booths
and filter assemblies in ventilation intake systems.

OPERATING RANGE

Maximum temperature: 80 °C (continuous operation)
Maximum relative humidity: 100%
Rated Velocity: 1.5 – 2.5 m/s

FILTER MEDIA

Media is needled and calendared ensuring a high break resistance and will retain the fibre matrix after cleaning.
Thermally bonded progressive density synthetic fibre.
Flame resistance class F1 (DIN 53438-3)

DISPOSAL

Partially regenerable.
Used filters may be disposed of in authorised landfill.
